Specification
| Camera Feature | ||
| Image Sensor | 1/2.7", 3.0 megapixel, progressive scan, CMOS | |
| IR Distance | Smart IR, up to 30m (98ft) IR distance | |
| Others | Minimum Illumination: Colour: 0.01Lux ( F2.0, AGC ON) 0Lux with IR Shutter: Auto/Manual, 1 ~ 1/100000s Material: Metal+Plastic |
|
| Lens | ||
| Type | 2.8mm and 4.0mm @2.0, Fixed-focal | |
| Focal Length | 850nm | |
| Aperture | Build-in-Mic | |
| Angle of View | 112.9° x 59.1° x 121.2° (H x V x D) | |
| Others | Lens Mount: M12 IR Distance: Up to 30m (98ft) IR range IR Control: Auto/Manual Flip: Normal/ Vertical/ Horizontal/ 180°/ 90°Clockwise/ 90°Anti-clockwise Digital Noice Reduction: 2D/ 3D DNR |
|
| Physical Specification | ||
| Dimension | Φ118 x 96mm (Φ4.6” x 3.8”) | |
| Weight | 0.30kg (0.86lb) | |
| Power | DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 7.0W |
|
| Interface | Power Interface: Ø 5.5mm coaxial power plug Network Interface: 1 * RJ45 10M/100M Base-TX Ethernet |
|
| Others | Working Environment: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) Water & Dust Protection: IP67 Reset Button: N/A Surge Protection: 4KV Network Storage: ANR, NAS(NFS) Defog: Digital Defog |
|
| Warranty | ||
| Warranty | 1 Year Warranty | |
